Steve Flanges is a renowned Canberra, Australia-based manufacturer and supplier of high-quality flanges for a range of industries. With proficiency in the manufacturing of Titanium Socket Weld Flanges, Steve Flanges supplies corrosion-resistant, light, and strong solutions to industries that need them. Precision and reliability are hallmarks of Steve Flanges, which ensures that every product has high standards for strength and performance. Their dedication to customer satisfaction and offering customized solutions has made them a reliable partner for clients operating in industries like oil and gas, petrochemical, and marine engineering. Steve Flanges provides outstanding products that ensure results with long durability.
Titanium Socket Weld Flanges are comprised primarily of titanium alloys, most of which is Grade 2 titanium, with excellent corrosion resistance, strength, and light weight. The flanges obtain higher pitting, crevice, and stress corrosion cracking resistance, especially in aggressive environments like seawater and chemicals. The mechanical strengths of Titanium Socket Weld Flanges are a tensile strength of about 350 MPa, yield strength of about 275 MPa, and elongation of 20%. These specifications provide maximum resistance and endurance with high pressure and temperature levels and are hence very suitable for various industrial applications.
| Trade name | Titanium (Ti) Socket Weld / Threaded Flange |
| Titanium Socket Weld / Threaded Flanges Standard | ASTM B381 / ASME SB381 ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges |
| Titanium Socket Weld / Threaded Flange Dimensions | B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN |
| Titanium Socket Weld / Threaded Flanges Size | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000) |
| Titanium Socket Weld / Threaded Flanges Class/Pressure |
|
| Flange Face Type | Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Titanium Socket Weld / Threaded Flanges Marking | All Flanges are marked as follows: Grade, Standard, Thickness, Heat No. (Or according to the customer’s request.) |
| Delivery Time | 7-15 working days as usual, It will based on the detailed order quantity. |
Steve Flanges, a leading supplier in Canberra, Australia, offers an extensive selection of Titanium Socket Weld Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Titanium Socket Weld Flanges have extensive applications across industries where they need to deliver corrosion resistance, high strength, and light-weight characteristics. Titanium Socket Weld Flanges are popularly used across the oil and gas, petrochemical, chemical processing, and power industries. Because they are resistant to corrosion, these flanges have applications in rigorous environments like seawater, chemical plants, as well as extreme temperature applications. These flanges are commonly employed in pipe systems, especially where space is restricted and high-pressure connections are required. Their resistance to harsh conditions makes them a necessity for equipment such as heat exchangers, reactors, desalination plants, and offshore platforms, guaranteeing efficient and long-term performance.
| Element | Titanium | Nitrogen | Carbon | Hydrogen | Iron | Oxygen | Residuals (each) | Residuals (total) |
| % | Balance | 0.03 max | 0.08 max | 0.015 max | 0.30 max | 0.25 max | 0.1 max | 0.4 max |
| 0.2% Proof Stress | Tensile Strength | Elongation | |
| MPa | MPa | % | |
| Annealed | 275-450 | 345 | 20 |
Yes, we offer custom sizes for Titanium Socket Weld Flanges to meet specific project needs. Our team at Steve Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@steveflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
