Steve Flanges is a well-respected manufacturer and supplier located in Canberra, Australia, known for crafting top-notch Titanium Flat Flanges that adhere to international industrial standards. The company prides itself on precision engineering, ensuring that every product boasts excellent dimensional accuracy, strength, and resistance to corrosion. These flanges are designed for straightforward installation and dependable performance, even in high-pressure and high-temperature settings. Steve Flanges caters to a diverse array of industries, including chemical processing, aerospace, marine, and power generation, providing Titanium Flat Flanges that promise durability, efficiency, and a long service life in demanding industrial applications both in Australia and around the globe.
Titanium Flat Flanges are mainly made from titanium, often mixed with small amounts of aluminum, vanadium, or molybdenum, depending on the specific grade. This unique blend offers remarkable corrosion resistance, lightweight characteristics, and an impressive strength-to-weight ratio. They showcase tensile strengths ranging from 240 to 1000 MPa, along with outstanding ductility and toughness. The protective oxide layer on titanium ensures excellent resistance to oxidation and chemical damage, even in the harshest environments. These mechanical properties make Titanium Flat Flanges perfect for applications that demand long-lasting durability, stability, and the ability to withstand extreme temperatures and pressures.
| Product Name | Titanium Flat Flanges |
|---|---|
| Size Range | 1/2″ (15 NB) to 48″ (1200NB) |
| Class / Pressure Rating | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standards / Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605 |
| Titanium Flat Face Flanges / Connection Type | Flat Face Flange (FF), Raised Face Flange (RF), Ring Joint Flange (RTJ), Lap Joint Flange, Male and Female Flange (M&F), Large and Small Tongue-and-Groove Flange (T&G) |
| Dimensions | ANSI B16.5, ANSI B16.47 Series A & B, ASA, API-605, MSS SP44, AWWA, Custom Drawings |
| Custom Design | As per your drawing | AS, BS, ANSI, DIN, JIS | Equal and Reducing Configurations |
| Material Test Certificates (MTC) | As per EN 10204 3.2 and EN 10204 3.1, Test Certificates certifying NACE MR0175, NACE MR0103 |
| Test Certificates | 100% Radiography Test Report, EN 10204/3.1B, Raw Materials Certificate, Third Party Inspection Report, etc |
| Tests | Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment / Machines | Press machine, Pushing Machine, Bending machine, Sand-blasting machine, electric bevelling machine, etc. |
Steve Flanges, a leading supplier in Canberra, Australia, offers an extensive selection of Titanium Flat Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Titanium Flat Flanges find their place in industries where corrosion resistance and structural integrity are paramount. They’re frequently used in chemical processing facilities, desalination plants, oil and gas refineries, and marine applications due to their capability to endure seawater and aggressive chemicals. In the aerospace and power generation sectors, these flanges offer lightweight yet sturdy connections for high-performance systems. Additionally, they are utilized in heat exchangers, pipelines, and pressure vessels to ensure secure, leak-proof joints, delivering efficiency and reliability in challenging and corrosive operational environments.
| STANDARD | UNS | WERKSTOFF NR. |
| Titanium Gr 2 | R50400 | 3.7035 |
| Titanium Gr 5 | R56400 | 3.7165 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | .08 Max | .03 Max | .18 Max | .015 Max | Bal | .20 Max |
| Titanium Grade 4 | .08 Max | .05 Max | .40 Max | .015 Max | Bal | .50 Max |
| Titanium Grade 7 | .08 Max | .03 Max | .25 Max | .015 Max | Bal | .30 Max |
| Titanium Grade 9 | .08 Max | .03 Max | .15 Max | .015 Max | – | .25 Max |
| Titanium Grade 12 | .08 Max | .03 Max | .25 Max | 0.15 Max | – | .30 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 G/Cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| 4.43 G/Cm3 | 1632 °C (2970 °F) | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
Yes, we offer custom sizes for Titanium Flat Flanges to meet specific project needs. Our team at Steve Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@steveflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
