Steve Flanges, a top-notch manufacturer and supplier located in Canberra, Australia, specializes in high-quality **Inconel Flat Face Flanges** that are built to last, ensuring reliability and outstanding performance even in harsh, high-temperature environments. Crafted with precision from premium Inconel alloys, these flanges boast remarkable resistance to oxidation, stress, and thermal fatigue. Their completely flat sealing surface guarantees a secure and uniform connection in low-pressure piping systems. Steve Flanges provides **Inconel Flat Face Flanges** that adhere to international standards, making them perfect for **chemical, marine, power generation, and oil and gas** applications that demand long-lasting performance and safety.
These **Inconel Flat Face Flanges** primarily consist of **nickel (up to 72%) and chromium (14–17%)**, along with small amounts of iron, molybdenum, and niobium to boost their mechanical strength and corrosion resistance. They showcase a **tensile strength of 930–1000 MPa** and impressive yield strength, even when faced with thermal stress. The unique makeup of the alloy provides exceptional resistance to **oxidation, pitting, and chloride-induced corrosion**, ensuring they maintain their structural integrity in extreme conditions like high-temperature and high-pressure applications.
Steve Flanges, a leading supplier in Canberra, Australia, offers an extensive selection of Inconel Flat Face Flanges including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Specifications | ASTM B564 / ASME SB564 |
|---|---|
| Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Size | 1/2″ (15 NB) to 48″ (1200NB) |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Flange Face Type | Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Grade | Ni | Si | C | S | Mn | Cr | Fe | |
| Inconel Flat Face Flanges | min. | 72.0 | – | – | – | – | 14.0 | 6.0 |
| max. | – | 0.5 | 0.15 | 0.015 | 2.0 | 17.0 | 10.0 | |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness (Brinell) |
| Inconel Flat Face Flanges | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % | – |
You’ll find **Inconel Flat Face Flanges** widely used in **chemical processing units, desalination plants, power generation facilities, heat exchangers, and marine engineering systems**. Their flat surface guarantees a tight and dependable seal when paired with flat-faced gaskets, making them ideal for **low-pressure and non-cyclic piping connections**. These flanges are perfect for transporting **acidic, alkaline, or seawater-based fluids**, effectively preventing leaks and ensuring joint stability. Thanks to their impressive strength and corrosion resistance, they are also a popular choice in **oil refineries, offshore structures, and aerospace systems**, providing reliable long-term operation.
Yes, we offer custom sizes for Inconel Flat Face Flanges to meet specific project needs. Our team at Steve Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@steveflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
