At our Canberra facility, we take pride in crafting and supplying top-notch carbon steel RTJ flanges, specifically designed for high-pressure industrial piping systems that demand dependable, metal-to-metal sealing. Our selection features both forged and machined RTJ flanges made from high-quality carbon steel grades (like ASTM A105/A105N and A350 LF2) and adheres to key international standards (including ASME B16.5, ASME B16.47, DIN, and EN). Our manufacturing process focuses on precision machining of the ring-groove face, strict material traceability, and comprehensive certification, guaranteeing leak-tight performance even in the toughest service conditions.
Carbon Steel RTJ (Ring-Type Joint) flanges consist mainly of carbon steel with minute proportions of manganese, silicon, sulfur, and phosphorus Their mechanical properties are high tensile strength (up to 530 MPa), good yield strength (approximately 250 MPa), and good ductility They are more resistant to shock and fatigue and thus are stronger at high pressures. Benefits of carbon steel RTJ flanges are low price, availability, and high pressure and high temperature resistance properties, rendering them suitable for oil, gas, petrochemical and other applications.
| Specification | ASTM A694 / ASME SA694 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Ring Type Joint (RTJ), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM A694 F316 Carbon Steel Flanges |
| Grades | Carbon Steel A105, IS2062, LF2, F42, A36, F52, F56, F65, F60, F70, F80 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Our carbon steel RTJ flanges are crafted from premium forged carbon steel, offering outstanding tensile strength, yield strength, and stability under high pressure and temperature. The RTJ groove is meticulously machined to ensure the metal ring gasket seats perfectly, allowing for safe and consistent sealing in critical applications. Through rigorous inspection and testing, we make sure that the mechanical and dimensional properties meet or surpass client specifications and industry standards.
Carbon steel RTJ (ring type joint) flanges are mostly employed at high pressures and temperatures because of their tight sealing qualities They are most suitable for use in the oil and gas industry, petrochemical plants, power generation and chemical a is used in an RTJ system that places a metal ring on the flange face for a robust leakproof seal, hence making these flanges fit to withstand harsh conditions, such as extreme pressures and temperatures hard included Carbon steel RTJ flanges are very resistant, mostly in pipelines, applied in reactors, and other key systems.
| ASME/ANSI B 16.5 | RTJ Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | RTJ Flange [Series A & B],Welding Neck Flange |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | RTJ Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Hubbed Slip-On |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | Hubbed Slip-On Hubbed Threaded |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Plate Slip-On Flange, Slip-On Boss Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
These carbon steel RTJ flanges find their place in various industries, including oil & gas, petrochemical, power generation, water treatment, and offshore installations. They are perfect for pipe connections, valve interfaces, equipment isolations, and hot/high-pressure systems where enhanced sealing reliability is essential. Plants and projects throughout Canberra and Australia trust our carbon steel RTJ flanges for their durability, compliance, and long-lasting performance.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
